Hlau EDM khoom

CFY tshwj xeeb hauv edm machining, edm txiav, xaim edm khoom thiab tau ua tiav kev koom tes nrog cov tuam txhab hauv cov haujlwm no. Peb muaj ntau tshaj 14 xyoo kev paub ntawm daim teb no uas muab peb qhov tob, kev paub & kev paub txog molding. Hauv peb lub sijhawm pab cov neeg siv khoom tsim cov khoom thiab cov khoom peb tau pom thiab ua tiav tag nrho. Kev paub & kev txawj ntse yog qhov tseem ceeb thaum nws los txog rau kev tsim khoom.



Cov txiaj ntsig ntawm Kev Siv Hlau EDM rau Iav Txiav

Siv hlau EDM (Electrical Discharge Machining) rau kev tsim thiab txiav cov iav yog cov txheej txheem tsim tau zoo, tshwj xeeb tshaj yog thaum cuam tshuam nrog cov khoom tshwj xeeb xws li helical iav, bevel iav, thiab lwm yam iav tshuab. Cov intricacies koom nrog hauv iav txiav ua kom txo qis machining cov kauj ruam xav tau.



Hlau EDM ua haujlwm li cas?

Nyob rau hauv no machining txheej txheem, lub workpiece yog immersed nyob rau hauv ib tug dielectric kua, mechanically clamped siv ib tug hlau EDM vise, thiab ces ib tug hlau yog threaded los ntawm lub workpiece, generating sparks thaum ib tug hluav taws xob tam sim no dhau los.



Hauv lwm lo lus, ib sab ntawm cov xaim nqa tus nqi, thaum lub workpiece (uas yuav tsum yog cov khoom siv hluav taws xob) nqa cov nqi sib txawv. Thaum lawv los ze, cov nqi thermal dhia qhov sib txawv, melting me me hlau hais.



Cov hluav taws xob tawm yog cov cuab yeej txiav uas tsim cov khoom raws li xav tau. Tsis tas li ntawd, cov txheej txheem xaim EDM yuav tsum tau siv cov dej deionized los tswj cov txheej txheem thiab tshem tawm cov khoom me me.



Vim lub precision ntawm hlau EDM, lub zog yuav tsum tau tsawg dua tom qab ua tiav ib feem. Qhov no yog qhov tseem ceeb tshwj xeeb tshaj yog thaum txiav txim siab zero-interference tsim thiab tiv thaiv meshing cuam tshuam hauv cov iav. Hlau EDM machining tshem tawm qhov xav tau rau cov cuab yeej tshwj xeeb (ib sab ntawm cov hlau nws tus kheej) thiab cov khoom siv tshwj xeeb, ua kom ncaj ncaj kom ua tiav qhov kev txiav ntxhib rau lub zog. Qhov nyuaj ntawm hlau EDM machining kuj tau txais txiaj ntsig los ntawm lub tshuab muaj peev xwm los txiav cov yam ntxwv sab hauv, splines, thiab lwm yam tseem ceeb ntawm cov iav. Tsis tas li ntawd, piv rau cov txheej txheem machining ib txwm, lub sijhawm rau kev txiav cov hlau tawv tawv thiab cov hlau yog luv dua, txo cov sij hawm txhuas thiab ua kom cov txheej txheem tsim cov iav.

Nyob rau ntawm lub sijhawm no, kev siv hlau EDM tshem tawm qhov kev xav tau ntawm kev tshaj tawm lossis, qee zaum, tshem tawm tag nrho cov kev xav tau rau kev siv zog broaching. Broaching feem ntau yog siv cov cuab yeej tshwj xeeb (hu ua hobs) kom tshem tawm cov khoom los ntawm qhov sib txawv. Gears feem ntau yog cov khoom uas yuav xav tau broaching, nyob ntawm lawv daim ntawv thov. Txawm li cas los xij, nrog hlau EDM machining, broaching tsis tas yuav tsum tau, txuag ob lub sijhawm thiab nyiaj txiag hauv kev tsim khoom.



Siv hlau EDM tshuab rau iav txiav kuj muaj txiaj ntsig ib puag ncig. Txij li tsis muaj kev xav tau rau kev txiav cov roj uas feem ntau siv hauv kev ua haujlwm ib txwm siv, tsis muaj kev tuav cov dej paug lossis siv cov kuab tshuaj, cov kuab tshuaj, lossis cov chips hlau. Qhov no txo ​​cov kev cuam tshuam ib puag ncig thiab txo qhov kev pheej hmoo ntawm kev raug mob rau cov tshuab tshuab. Nws kuj txhais tau tias tshem tawm cov nqi cuam tshuam nrog kev tuav cov roj thiab cov hlau chips, ua rau ob qho tib si manufacturers thiab ib puag ncig cov ntsiab lus ntxiv.



Ntim Cov Lus Qhia: Carton, Ntoo rooj plaub, pallet, lossis raws li cov neeg siv khoom xav tau.

Tus me nyuam nthuav dav: 25-35 hnub los ntawm hiav txwv, 3-7 hnub los ntawm huab cua







Cim npe nrov: Hlau EDM khoom, Tuam Tshoj hlau EDM khoom manufacturers, lwm tus neeg, Hoobkas
