Micro EDM
Chien Feng Yuan yog ib tug ua EDM (Electrical Discharge Machining), hlau edm manufacturing thiab edm txiav kev pab cuam tshuab rhiav raws li nyob rau hauv Taiwan.
- Khoom Taw qhia
Chien Feng Yuan yog ib tug ua EDM (Electrical Discharge Machining), hlau edm manufacturing thiab edm txiav kev pab cuam tshuab rhiav raws li nyob rau hauv Taiwan. Peb muab Molybdenum hlau txiav EDM, micro edm rau tag nrho koj precision machining xav tau. Pab cov neeg siv khoom thoob ntiaj teb rau 14 xyoo, peb cov kev txawj ntse txuas mus rau aerospace, khoom siv kho mob, kev lag luam, tub rog, thiab kev lag luam tiv thaiv. Hauv peb lub sijhawm pab cov neeg siv khoom tsim cov khoom thiab cov khoom peb tau pom thiab ua tiav tag nrho. Kev paub & kev txawj ntse yog qhov tseem ceeb thaum nws los txog rau kev tsim khoom.
Qhov zoo ntawm Hlau EDM Machining
Precision Txiav:
Nws tso cai rau kev txiav meej yam tsis tas yuav tsum tau ua haujlwm ntxiv thiab ua tiav ntawm cov khoom ua haujlwm.
Complex Designs:
Cov txheej txheem yog tsim los tsim intricate designs thiab cov duab uas nyuaj rau tsim nrog ib txwm CNC machining.
Qhov me me thiab nthuav dav heev:
Hlau EDM yog qhov zoo rau kev ua cov khoom me me thiab txiav cov khoom nrog cov ntsiab lus siab uas tej zaum yuav muag heev rau lwm yam kev xaiv machining.
Cov ntaub ntawv nrog tsawg machinability:
Hlau EDM yog tshwj xeeb tshaj yog haum rau cov ntaub ntawv uas nkig thiab tsis tuaj yeem tiv taus machining kev nyuaj siab.
Single-Stage Processing:
Lub tshuab tuaj yeem txiav cov ntaub ntawv hauv ib theem, tsis muaj burrs lossis deformations.
Nruam txiav:
Kev ua haujlwm suav nrog kev txiav tsis tu ncua, thiab txawm tias cov hlau tawg thaum txiav, cov txheej txheem tuaj yeem rov ua haujlwm tam sim ntawd.
Disadvantages ntawm Hlau EDM Machining
Nws tsuas yog sib xws nrog cov khoom siv hluav taws xob.
Qhov chaw txiav ntawm qee cov ntaub ntawv (xws li txhuas) tuaj yeem tsim cov txheej txheem oxide, uas yuav tsum tau ua tiav cov txheej txheem ntxiv thiab yog li nce nqi.
Siab pib peev thiab cov nqi kho mob.
Kev siv hluav taws xob tso tawm Machining
Electrical Discharge Machining (EDM) tshwj xeeb tshaj yog muaj npe nrov rau kev tsim khoom me me, ua kom muaj ntau yam txheej txheem xws li milling, tig, thiab qhov me me drilling. Cov cuab yeej tshwj xeeb no muaj txiaj ntsig thoob plaws ntau yam kev lag luam, los ntawm tsheb mus rau aerospace.
Lub peev xwm ntawm cov thev naus laus zis no los tsim cov duab sib txawv thiab meej yog qhov zoo rau ntau yam kev siv, suav nrog:
Txhaj Molding:
Kev ua tiav qhov pwm qhov tseeb, qhov tob, thiab cov duab feem ntau yog nyob ntawm EDM. Nws yog thawj txoj kev txhaj tshuaj molding siv los ntawm cov tuam txhab pwm. Hlau EDM yog hom dav siv hauv qhov no. Muab hais tias kev txhaj tshuaj molding muaj ntau yam sib txawv, cov qauv no feem ntau yog qhov kev xaiv. Ntxiv mus, nws feem ntau tuaj yeem tsim cov high-precision thiab finely tiav nto los ntawm hluav taws xob tawm machining.
Lub tshuab no ua lub luag haujlwm tseem ceeb hauv kev tsim cov khoom siv rau kev txhaj tshuaj molding, ua kom cov pwm tsim nrog cov qhov ntev thiab cov ntsiab lus sib txawv. Nws muaj peev xwm ua haujlwm nrog ntau yam khoom siv, suav nrog cov uas nyuaj thiab nkig, ua rau nws muaj ntau yam thiab muaj txiaj ntsig zoo hauv kev tsim khoom.
Tuag Casting
EDM machining kuj tseem tsim nyog rau kev tsim pwm. Kev tsim cov pwm tsim tshwj xeeb xav tau tshwj xeeb precision. Cov pwm no feem ntau ua rau cov ces kaum sab hauv, sib sib zog nqus tav, thiab lwm yam khoom siv. Tsis tas li ntawd, cov pwm feem ntau yog ua los ntawm cov hlau tsis tshua muaj zog. Cov alloys no feem ntau nyuaj rau tshuab siv cov txheej txheem pa. Hard steel alloys yuav xav tau precision machining ua ntej kev kho cua sov, uas tuaj yeem cuam tshuam qhov tseeb ntawm cov ntsiab lus. Yog li ntawd, kev txais yuav cov txheej txheem EDM yog qhov tsim nyog dua.
Product details:
Ntim Cov Lus Qhia: Carton, Ntoo rooj plaub, pallet, lossis raws li cov neeg siv khoom xav tau.
Tus me nyuam nthuav dav: 25-35 hnub los ntawm hiav txwv, 3-7 hnub los ntawm huab cua
FAQ
Q: Dab tsi ua haujlwm tuaj yeem ua los ntawm WEDM?
Hlau EDM (Electrical Discharge Machining) tuaj yeem siv rau machining pwm thiab cov cuab yeej nrog cov qhov sib txawv thiab cov kab noj hniav. Nws ua ntau yam ntaub ntawv nyuaj thiab nkig, xws li tawv alloys, hardened steel, thiab lwm yam. Nws muaj peev xwm ntawm machining qhov sib sib zog nqus qhov, qhov zoo, qhov tob tob, qhov khoob khoob, thiab nyias ntu. Nws kuj yog siv rau machining ntau yam shaping cuab yeej, xov gauges, thiab ntsuas ntsuas. Ntev npaum li cov khoom siv hluav taws xob, xaim EDM tuaj yeem ua haujlwm rau kev ua haujlwm.
Q: Dab tsi yog qhov txwv ntawm EDM?
Cov txheej txheem EDM tshem tawm cov ntaub ntawv them nqi, txhais tau hais tias nws tsuas yog txwv rau cov khoom siv hluav taws xob thiab tsis haum rau cov khoom sib xyaw lossis cov khoom siv dielectric. Hlau EDM tuaj yeem ua rau tsim cov oxide txheej ntawm cov hlau tshwj xeeb, yuav tsum tau ntxuav kom zoo kom zoo.
Discharge machining ntsib cov teeb meem nrog cov khoom thiab cov khoom uas tuaj yeem kho kom ruaj ntseg tsis cuam tshuam rau lawv cov duab. Piv txwv li, cov tubular qhov chaw yuav deform thaum lub sij hawm hluav taws xob tawm txiav, ua rau muaj teeb meem zoo.
Lwm drawbacks ntawm hluav taws xob paug machining muaj xws li:
Slower Processing Sijhawm:
EDM feem ntau muaj lub sijhawm ua haujlwm qeeb dua piv rau lwm txoj hauv kev machining.
Kev hnav ntau dhau ntawm cov cuab yeej electrode:
Cov cuab yeej hluav taws xob yuav muaj kev hnav ntau dhau thaum lub sijhawm machining.
Reproducing Sharp Corners yuav tsis yog ib txwm ua tau:
Ua kom tiav qhov kev tsim tawm ntawm cov kaum ntse ntse yuav tsis yog ib txwm ua tau.
Metallurgical Hloov:
Cov khoom siv metallurgical ntawm cov ntaub ntawv tuaj yeem hloov pauv vim qhov kub thiab txias thaum lub sijhawm ua haujlwm.
Kev Kho Kom Zoo Ntawm Qhov Sib Nrauj Electrodes:
Qhov tob-qhov electrodes feem ntau yuav tsum tau kho ntau zaus.
Cov Kev Sib Tw Hauv Kev Tshawb Nrhiav Cov Neeg Ua Haujlwm EDM Cov Haujlwm:
Nrhiav kev paub txog EDM cov tswv lag luam tuaj yeem nyuaj.
Kev siv hluav taws xob siab:
Cov tshuab EDM siv hluav taws xob ntau heev.
